Description
The D.I.D ZVM-X2 Series utilizes our patented X-Ring seal and has greater strength than the VX Series and is designed for heavyweight motorcycles with tremendous torque and horsepower. The twisting action of the X-Ring® increases its sealing performance and its four contact points minimizes power loss. The ZVM-X Series’ Direct Energy Transfer, born from our experience in MotoGP, means greater stretch resistance under load.
The ZVMX2 chain is a great chain for high powered street bikes but may also be utilized on adventure bikes such KTM 1290, 790, 890, Africa Twin, Tenere 700
**ZVM-X and ZVM-X2 CONNECTING LINKS AREN'T INTERCHANGABLE** (Varying pin lengths)
Specifications
| Max CC: | 1,300cc |
| Tensile Strength: | 10,408 lbs |
| Weight (100L): | 4.65 lbs |
| Seal: | X-Ring |
| Chain Life Index: | 4,000 |
| Pin Length: | 0.913" |
| Pin Diameter: | 0.217" |
| Inner Plate Thickness: | 2.4 |
| Outer Plate Thickness: | 2.6 |
Part Numbers
| Option name | MFR. Part Number | SKU | Stock |
| 100L / Gold | M525ZVMX2G100 | K-079213 | Available |
| 110L / Gold | 525ZVMX2G110 | K-079214 | Available |
| 120L / Natural | 525ZVMX2X120 | K-079230 | Available |
| 120L / Gold | 525ZVMX2G120 | K-079207 | In stock |
| 122L / Gold | M525ZVMX2G122 | K-079208 | Sold out |
| 120L / Black | 525ZVMX2B120 | MV-40-67251 | In stock |
| 130L / Gold | 525ZVMX2G130 | MV-40-66071 | In stock |
